The XPA-9 is powered by a high efficiency, audiophile grade, Switch Mode Power Supply (SMPS)

The new XPA-9 is a nine-channel audiophile quality power amplifier. The XPA-9 is populated with five of our High-Powered Single Channel Modules, and two of our Stereo Modules, for a total of five high-powered channels and four lower-powered channels. This combination is ideal for a surround sound system that is used for both music and home theater listening, and includes height speakers.

In a 5.1.4 system, the front speakers and surrounds are powered by high-powered channels, while the height speakers are driven by the lower powered stereo modules. In a 7.1.2 system, the front speakers and side surrounds are powered by high-powered channels, while the less critical rear surrounds and height speakers are driven by the lower powered stereo modules. Even though the channels differ in terms of maximum power output, they feature perfectly matched electrical characteristics, and the same superb Class A/B sound quality.

The XPA-9 is perfect for powering:

• A 5.1.4 Dolby Atmos or DTS-X system
• A 7.1.2 Dolby Atmos or DTS-X system
• A 5.1 channel system with two additional pairs of speakers in other zones
• A 7.1 channel system with one additional pair of speakers in another zone
• A 7.1 or 7.2 channel system that also includes two pairs of smaller speakers in other zones

The power output capabilities of the various channels on the XPA-9 were optimized to provide the best sound quality in real-world listening conditions; the main channels, which are the most critical for both dynamic music reproduction and crystal clear dialog, receive the most power.

• 300 watts RMS/channel; 20 Hz – 20 kHz; THD<0.1%; 8 Ohms; one channel driven.
• 550 watts RMS/channel; 20 Hz – 20 kHz; THD<0.2%; 4 Ohms; one channel driven.
• 300 watts RMS/channel; THD<0.1%; 8 Ohms; two channels driven.
• 490 watts RMS/channel; THD<0.1%; 4 Ohms; two channels driven.
• Power Bandwidth (at rated power; 4 Ohm - 8 Ohm load): 20 Hz to 20 kHz (+ / – 0.1 dB).
• Broad Band Frequency Response: 5 Hz to 80 kHz +0/-2 dB.
• THD + noise: < 0.005%; at 100 watts RMS; 1 kHz; 8 Ohms.
• Signal to Noise Ratio (8 Ohm load):> 115 dB; ref FTC rated power; unbalanced input (A-weighted).> 86 dB; ref 1 watt; unbalanced input (A-weighted).
• Minimum Recommended Load Impedance (per channel): 4 Ohms (which equals one 4 Ohm load or two paralleled 8 Ohm loads).
• Damping Factor (8 Ohm load): > 500.
• Input Sensitivity (for rated power; 8 Ohm load): 1.71 V.
• Gain: 29 dB
• 17” wide x 8” high x 19” deep (unboxed; including feet)
• 17” wide x 7” high x 19” deep (unboxed; without feet).
• 24-1/2” wide x 12” high x 24-3/4” deep (boxed).
• 53 lbs (unboxed).
• 58 lbs (boxed).
